Paediatric ECG

Use the following chart as a quick checklist to review what’s normal and what’s not in a paediatric ECG.

Remember:

  • Lead V4R in under5’s
  • Manually calculate QTc
  • WPW needs referral for ablation – increase risk of sudden death

If in any doubt discuss with paediatric registrar/senior. If in need of urgent interven:on then contact the paediatric cardiology team in LGI.

This website interpretation tool makes this even easier!

1. Placement of Leads: Precordial Leads

In young children, the right ventricle normally extends to the right side of the sternum. To appropriately display right ventricular potentials, ECGs for children in the under five-year age group must include an alternate lead (‘V4R’) on the right side of the chest at a point analogous to the left sided V4.

2. P Waves:

3. Axis:

In utero- high pulmonary pressures and a relatively thick Right Ventricle (RV) -> Initial Right Axis on ECG is normal and resolves after the first 6 months of life

QRS Axis Deviation

  • Chest leads in wrong position



RAD:

  • Newborns
  • RVH secondary to Right ventricular outflow tract obstruction eg: Pulmonary
    Stenosis ,Tetralogy Of Fallot, Noonans (characterized by mildly unusual facial features, short stature, heart defects, bleeding problems, skeletal malformations, and many others)
  • RBBB



LAD:

  • LBBB
  • LVH secondary to LVOTO (Left Ventricular Outflow Tract Obstruction) e.g. Aortic Stenosis, HOCM



Superior Axis

  • AVSD (Atrio ventricular septal defect – Trisomy 21)
4. QTc:

Manually calculate QTc – HERE

Normal QTc:

  • Infants less than 6 months = < 0.49 seconds.
  • Older than 6 months = < 0.44 seconds.

QTc is prolonged in:

  • Hypocalcaemia
  • Myocarditis
  • Long QT syndromes such as Romano-Ward Drugs

QTc is short in:

  • Hypercalcaemia
  • Congenital short QT syndrome
5. Ventricular Hypertrophy

6. T waves:
  • The precordial T-wave configuration changes over time
  • For the first week of life, T waves are upright throughout the precordial leads.
  • After the first week, the T waves become inverted in V1-3 (= the “juvenile T-wave pattern”)
  • This T-wave inversion usually remains until ~ age 8; thereafter the T waves become upright in V1-3.
  • However, the juvenile T-wave pattern can persist into adolescence and early adulthood (= “persistent juvenile T waves”).

Tall, peaked T waves are seen in:

Hyperkalaemia, Dilated LV (volume overload), Benign early repolarisation



Flat T waves are seen in:

Normal newborns, Hypothyroidism, Hypokalaemia, Pericarditis, Myocarditis

7. ST Segment:

Some ST changes may be normal:

  • Limb lead ST depression or elevation of up to 1mm (up to 2mm in the left precordial leads).

  • J-point depression: the J point is depressed without sustained ST depression, i.e. upsloping ST depression

  • Benign early repolarisation in adolescents: the ST segment is elevated and concave in leads with an upright T wave.





Others are pathological:

  • A downward slope of the ST followed by a inverted T.

  • A sustained horizontal ST segment depression





Pathological ST segment changes are commonly associated with T wave changes and occur in:

  • Pericarditis.

  • Myocardial ischaemia or infarction.

  • Severe ventricular hypertrophy (ventricular strain pattern)

Thanks to the paediatric dept for supplying the guidance –  trust PDF here

Neonatal Seizures

Seizures are a common neurological emergency in the neonatal period, occurring in 1–5 per 1000 live births.1 The majority of neonatal seizures are provoked by an acute illness or brain insult with an underlying aetiology either documented or suspected, that is, these are acute provoked seizures (as opposed to epilepsy). They are also invariably focal in nature.

Clinical diagnosis of neonatal seizures is difficult. This is in part because there may be no, or very subtle, clinical features, and also because neonates frequently exhibit non-epileptic movements that can be mistaken for epileptic seizures.

If interested the full guideline pan Yorkshire Neonatal Seizure Guideline can be found here

Read more

Neonatal Resus

PUT OUT A NEONATAL CRASH CALL

CRH – will result in at least a Neonatal SpR, SHO +/- a neonatal nurse.

HRI – may not generate a response. Consider a crash bleep to anaesthetics

CALL NEONATAL CONSULTANT (WILL ONLY GIVE ADVICE AS AT CRH)

CALL THE ED CONSULTANT

***Remember Grab Box***

Unless within the first few hours of life using the APLS algorithm is equally if not more appropriate

Paediatric Hypoglycaemia

Paediatric Hypoglycaemia (BM <2.6) is a relatively common presentation in the Emergency Department. However, if we don’t do the BM it’s easy to miss.

Hypoglycaemia in paediatric diabetic patients is managed separately – see here

Hypoglycaemia in neonates (<72 hours of life) also has specific management – see here (Flowcharts A + B)

Hypoglycaemia is generally caused by disruption in one of the following:

  • Carbohydrate intake
  • Carbohydrate absorption
  • Gluconeogenesis
  • Glycogenolysis

Read more

DKA in Kids

Diabetic Ketoacidosis – remember in paediatrics this may be the 1st presentation of diabetes.

  • Fluid – are more considered than adults due to the risk of cerebral oedema
  • Insulin – WAIT – need 1hr of fluid first
  • Paeds – involve them early
  • USE the BSPED DKA Management flow charts, calculators and full guidelines for when electrolytes won’t play ball which are all linked below.

DKA Management Calculator (recommended by paediatrics)- HERE

DKA Management Flow Chart – HERE

Full CHT DKA Guideline – HERE

Read more

Diabetic Hyperglycaemia (Kids)

Diabetic children sometimes attend ED with hyperglycaemia, but not in DKA (what should we do?)

Paeds have produced some advice to follow:

  1. Ketones over 0.6?
    • <0.6: Encourage fluids & food, may need an insulin correction
    • >0.6: ask Question 2
  2. Are there clinical features of DKA?
    • NO: Encourage fluids & food, decide Insulin correction, will need to be monitored
    • YES: Will need Paeds admission
